LG 55″ 55VH7E VH7E-H Series Video Wall Digital Display
Artistic Immersion, Overwhelming Captivation
The impressive immersion generated by the extremely narrow 0.9 mm even-bezel becomes even more powerful with a high haze value. The 55VH7E-H delivers vivid content with no reflections, even under bright lights, allowing it to effectively captivate viewers and drive traffic to areas where it is installed.
Achieving Incredible Immersion
Seamless Large Screens with Extreme-Narrow Bezel
The borderless design, with its 0.9 mm* even bezel and 1.8 mm* BtB (Bezel to Bezel), verified by Nemko, minimizes bezel interference and delivers immersive and seamless content on assembled video wall screens.
Achieving Incredible Immersion
Image Gap Reduction
The 55VH7E-H includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.
Vivid and Dynamic Picture Quality
Higher Viewing Angle
Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the 55VH7E-H is high enough to display vivid colors throughout the screen with no distortion.
Vivid and Dynamic Picture Quality
Clear View with Anti-Glare Coating
Viewers can easily become frustrated by unnecessary reflections when watching a screen under brightly lit conditions. The 55VH7E-H has resolved this problem by increasing the haze value up to 44, enhancing content visibility and text readability.
Powerful Smart Signage Platform
High Performance and Great Scalability
Thanks to its built-in SoC and webOS smart signage platform, the 55VH7E-H can execute several tasks at once while providing smooth content playback without the need for a media player. As webOS supports HTML5 as a webbased platform and offers SDK(Soft Development Kit), it is even easier for SIs to build and optimize.
User-Friendly Smart Signage UX
Intuitive Menu Structure
The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trialand-error when exploring desired functions and managing displays.
User-Friendly Smart Signage UX
Dedicated GUI for Portrait Orientation
The conventional GUI(Graphic User Interface) was designed based on landscape-oriented consumer TV usage, so OSD(On Screen Display) wasn’t well-suited for screens in portrait mode. The OSD of the 55VH7E-H, however, consists of a long range menu, creating a comfortable and efficient business environment.
User Convenience
Easy Color Adjustment
Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.
User Convenience
Simple White Balance Adjustment
In conventional video walls, white balance was adjustable only in “full-white” mode, but the 55VH7E-H allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.
User Convenience
LAN Daisy Chain Management
A LAN daisy chain allows you to execute commands to control and monitor video walls and even update their firmwares at once.
User Convenience
Real-Time Care Service
The maintenance gets easier and faster with an optional service Signage365Care*, a cloud service solution provided by LG service. It remotely manages status of displays in client workplaces for fault diagnosis and remote-control services, ensuring the stable operation of a client’s business.
Tech Spec
-
Panel
Screen Size 55″ Resolution 1,920 x 1,080 (FHD) Brightness (Typ., cd/m²) 700 Contrast Ratio 1,200:1 Dynamic CR 500,000 : 1 (The luminosity ratio of Full Black/Full White color on video input condition.) Viewing Angle (H x V) 178 x 178 Surface Treatment Haze 44% Life Time (Typ.) 60,000 Hrs Operation Hours 24 Hrs Orientation Landscape & Portrait -
Connectivity
Input HDMI (2), DP, DVI-D, Audio, USB 2.0 Output DP, Audio External Control RS232C In/out, RJ45(LAN) In/out, IR In -
Mechanical Specification
Bezel Width 0.9 mm (Even), B to B 1.8 mm Weight (Head) 18.6 kg Packed Weight 25.3 kg Monitor Dimension (W × H × D) 1,211.4 x 682.2 x 86.5 mm Carton Dimensions (W × H × D) 1,353 x 855 x 263 mm VESA™ Standard Mount Interface 600 x 400 mm -
Environment Conditions
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 % -
Power
Power Supply 100-240V~, 50/60Hz Power Type Built-In Power -
Power Consumption
Typ. 220 W Max 260 W Smart Energy Saving 110 W -
Certification
Safety CB / NRTL EMC FCC Class “A” / CE / KC ErP Yes (EU Only) -
Media Player Compatibility
OPS type compatible Yes (Piggyback) -
Software Compatibility
Content Management Software SuperSign CMS Control and Monitoring Software SuperSign Control/Control+ -
Accessory
Basic Remote Controller, Power Cord, RS232C Cable, LAN Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual Optional Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V), OPS Kit (KT-OPSF)
Key Feature
- Brightness(Typ.) : 700 cd/m²
- Surface Treatment(Haze): 44%
- Bezel : 0.9 mm (Even)
- Depth : 86.5 mm
- Interface : HDMI(2)/ DP/ DVI-D/ USB 2.0/ RS232C/ RJ45/ Audio/ IR
Original price was: RM19,250.00.RM14,911.00Current price is: RM14,911.00.
