Description
Artistic Space Beyond Display
Beyond its informative features, LG OLED signage delivers excellent advertising effectiveness, redesigning space as a prestige-enhancing landmark with perfect blacks, explosive colours and innovative forms.
Exceptional Picture Quality
Perfect Black
Infinite contrast ratio and the deepest blacks: Self-lighting pixels switch off completely to reproduce blacks with no light bleed.
Exceptional Picture Quality
Explosive Colours
This state-of-the-art OLED Display generates over a billion rich and beautiful colours.
Exceptional Picture Quality
Wide Viewing Angle
LG OLED Signage delivers awe-inspiring picture quality across the entire screen, even from wide viewing angles.
Sleek & Slim Design
LG OLED Signage Display is unbelievably thin, a feature that allows easy installation by using less space. An immersive view is attained while maintaining a sleek look.
*Based on 55″.
Space-efficient Design
Hide in Plain Sight
When mounted, the subtle edge of the wallpaper OLED blends near seamlessly with the wall, giving audiences the impression that content is being played directly within the wall itself. Integrating with and adding to luxurious interior design, the wallpaper OLED is an effective method for delivering advertisements and information.
Truly Immersive Screen
N×N Expandable Screen Size
Tiling up displays in a vertical and/or horizontal layout provides viewers with an expansive and immersive viewing experience, in an even larger OLED display.
Convenient Management
LAN Daisy Chain Management
The LAN daisy chain feature allows users to control and monitor signage, distribute content, and even update firmware all at once.
Easy Installation
Wall Fixers Optimised for Simple Tiling
The overall installation process of the wallpaper OLED has gotten much easier. Once the dedicated wall fixers are driven into a wall, a display can be easily hung on them. Video wall tiling has become more convenient, thanks to its front installation feature, which departs from the conventional side-sliding method.
Easy Installation
Enhanced Flexibility of Cables
As a result of in-depth consideration of usage scenarios, improvements have been made to the flexibility of common cables connecting the display to the signage box. These new cables are pliable enough to be easily embedded in a wall or other structures.
PANEL
-
- Screen Size
- 55″
- Panel Technology
- OLED
-
- Aspect Ratio
- 16 : 9
- Native Resolution
- 1,920 x 1,080 (FHD)
-
- Brightness (Typ.)
- 400/150 cd/m2 (Average Picture Level 25%/100%)
- Viewing Angle (H x V)
- 178 x 178
-
- Response Time
- 1ms (G to G), 8ms (MPRT)
- Surface Treatment (Haze)
- Hard Coating (2H), Anti-reflection Treatment of the Front Polariser (Reflectance Typ. 1.2%)
-
- Life Time (Typ.)
- 30,000 Hrs
- Operation Hours
- 18 Hrs / 7 Days *Moving Video Only
-
- Orientation
- Landscape & Portrait
CONNECTIVITY
-
- Input
- HDMI, DP, USB 2.0 (2)
- Output
- DP, Audio
-
- External Control
- RS232C In/out, RJ45 (LAN) In/out, IR In
PHYSICAL SPECIFICATION
-
- Bezel Colour
- Black
- Bezel Width
- 0.9 mm (Even) *Off-Bezel
5.3 mm (T/L/R),11.0 mm (B) *On-Bezel
-
- Dimension (W x H x D)
- (Head) 1220.3 x 696.8 x 4.9 mm
(Signage Box) 782.8 x 238.4 x 34.7 mm
- Weight
- 10 kg (Set)
-
- Carton Dimensions (W x H x D)
- 1,350 x 837 x 250 mm
- Packed Weight
- 22.9 kg
SPECIAL FEATURES
-
- Special features
- Internal Memory (64GB), Temperature Sensor, Embedded CMS (USB Auto Playback, Local Contents Scheduling, Group Manager), Fail Over, Content Sync (RS232C, Local Network), OSD Rotation, Tile Mode Setting, Setting Data Cloning, Firmware Update by Network, SNMP, ISM Mode, Control Manager, Crestron ConnectedⓇ1), DPM, PM Mode, Wake on LAN, Power on Delay, HDMI-CEC2), SI Server Setting, webRTC
ENVIRONMENT CONDITIONS
-
- Operation Temperature Range
- 0°C ~ 40°C
- Operation Humidity Range
- 10% ~ 80%
POWER
-
- Power Supply
- 100-240V~, 50/60Hz
- Power Type
- Built-In Power
-
- Power Consumption Typ. / Max.
- 309 W / 318 W *8 Colour Bar
STANDARD(CERTIFICATION)
-
- Safety
- AS/NZS 60950,CB Scheme
- EMC
- AS/NZS CISPR32,RCM(Class A)
-
- ErP / Energy Star
- Yes / No
MEDIA PLAYER COMPATIBILITY
-
- OPS Type Compatible
- No
- External Media player Attachable
- Yes
SOFTWARE COMPATIBILITY
-
- Content Management Software
- SuperSign CMS
- Control and Monitoring Software
- SuperSign Control+ / Control
ACCESSORIES
-
- Basic
- Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, RS232 Cable (4p-4p), FFC Cables (for Connection Between Panel and Signage Box), DP Cable, LAN Cable, LC (VLC Cable), Wall Fixers, Wall Fixer Install Guide, Install Guide Sheets, Tapes (for Cabling and Dust Proof), Screws
