Description
Interactive Performance
Clean Touch Experience
LG proprietary touch technology can draw clean and accurate diagonal lines through controlling multi-touch gestures in great precision. Clean multi-touch experience with IR Spread is based on our in-house IR-Spread technology which provides better accuracy compared to conventional IR Matrix.
Interactive Performance
Multi Touch Experience
It provides a more realistic sense of touch since it can recognize up to 10 point-touches at once. Various touch-based customer services can be provided through the screen so that consumers will have unforgettable shopping experiences.
User Convenience
Slim Design for a Sleek Look
With slim bezel and depth, KT-T series is designed to fit compatible displays and provide better touch accuracy. This way, the display maintains its sleek and clean look even when multi-functions are added on.
User Convenience
Simple Installation
Just a few screws and brackets are needed to attach a touch overlay kit be to the display. With low cost and minimal effort, your display can have the added value of touch performance.
Application
By adding touch values to standard displays, the utilization possibilities expand to a surprising variety of places. Wherever the KT-T series is installed, its two-way communication maximizes user engagement as well as user convenience.
Tech Spec
-
Panel
Screen Size 65 Orientation Landscape & Portrait Compatible Products 65SM5(K)D, 65SE3(K)D -
Connectivity
Input USB -
Physical Specification
Bezel Width 32.7 mm Overlay Dimension (W x H x D) 1,496.9 × 871.9 × 29.3 mm Weight (Head) 12.9 kg Packed Weight 21.3 kg -
Environment Conditions
Operation Temperature 0°C to 40°C Operation Humidity 10% to 80% -
Power
Power Supply USB Max 1.8 W -
Touch
Touch type IR (Infrared Rays) Scattering Available object size for touch Φ6 mm↑ (Single), Φ8 mm↑ (Multi) Scan Time 15 ms ↓ Accuracy 2 mm (Over 90% Area) Interface USB 2.0 Protection Glass Thickness 2.8T (Anti-Glare) Protection Glass Transmission 85 ± 5% Operating System Support Windows 7, Windows 8, Windows 8.1, Windows 10, Android (Kernel Version 3.5 Over), Linux(Kernel Version 3.5 Over), Mac OS X (10.9 Over), Chrome (39 or Above) Multi Touch Point Max 10 Points -
Accessory
Basic Overlay Manual (CD), Pen (2), Pen Tray, Install Accessories
