Polycom PANO Wireless Content Sharing Presentation System
Polycom PANO Wireless Content Sharing Presentation System

Polycom PANO Wireless Content Sharing Presentation System

RM9,670.00
  • Part Number : 7200-84685-001, Polycom Pano.
  • Wireless Presentation System.
  • 4K 60fps RGB444 output, HDMI IN 4K 30fps, Miracast, Airplay, App, Cloud Casting, Touch.
  • Cables: 1 HDMI 1.8m, 1 CAT 5E LAN 3.6m, 1 USB Type-B 2m, Power: AMER – Type B, NEMA 5-15.
  • Maintenance Contract Required.
SKU: 7200-84685-102
Category:
Tags: , , ,

PANO – WIRELESS CONTENT SHARING DEVICE

Pano is the easiest way to connect and share content at work. From the moment you walk into the room, Pano invites you to connect from your personal device with a simple touch.

  • POWER
    • 54 VDC, 1.2A
    • LAN IN; Built-in, auto-sensing PoE+ IEEE 802.3at (Class 4)
  • USER INTERFACE
    • Gesture-based, multi-touch capable
  • CONNECTIVITY
    • 1X Ethernet 10/100/1000
    • 1X Ethernet 10/100/1000 (reserved for future use)
    • 802.11ac Wi-Fi wireless networking; IEEE 802.11a/b/g/n compatible
  • NETWORKING AND PROTOCOLS
    • Bluetooth 4.0
    • Miracast (Wifi-Direct)
    • AirPlay (Bonjour)
  • AUDIO OUTPUT
    • 1X 3.5mm
  • CONTENT INPUT/RESOLUTION
    • 1X HDMI/4K, 30fps
    • Airplay 1080p, 30fps
    • Miracast 1080p, 30fps
  • CONTENT OUTPUT/RESOLUTION
    • 1X HDMI/4K, 60fps. RGB444
    • 1X USB to HDMI (optional, dongle not included)
  • SECURITY
    • Secure Boot
    • Signed Software
    • 802.1X Network Authentication
    • TLS Version Control
    • Certificate Management
    • Encrypted Content/Media (AES)
    • Miracast (WPA2-AES)
    • Airplay (AES)
  • APPROVALS
    • FCC Part 15 (CFR 47) Class B
    • ICES-003 Class B
    • EN55022 Class B
    • CISPR22 Class B
    • VCCI Class B
    • EN55024
    • EN61000-3-2; EN61000-3-3
    • Australia RCM
    • ROHS compliant
  • ENVIRONMENTAL
    • Operating Temperature: 32—104°F (0—40°C)
    • Relative humidity: 5—95%, noncondensing
    • Storage Temperature: -40—160°F (-40°—70°C)
  • ELECTRICAL SAFETY
    • UL 60950-1
    • CE Mark
    • CAN/CSA-C22.2 No. 60950-1-03
    • EN 60950-1
    • IEC 60950-1
    • AS/NZS 60950-1
  • RADIO
    • FCC Part 15.247
    • FCC Part 15.407
  • EU
    • ETSI EN 300 328
    • ETSI EN 301 893
    • ETSI EN 301 489-1
    • ETSI EN 301 389-17
  • JAPAN
    • Article 2, Paragraph 1, Item (19)
    • Article 2, Paragraph 1, Item (19) -2
    • Article 2, Paragraph 1, Item (19) -3
    • Article 2, Paragraph 1, Item (19) -3-2
  • AUSTRALIA
    • AS/NZ4268
  • WIFI
    • 2.4GHz – 5GHz
    • 2400MHz to 2483.5MHz
    • 5150MHz to 5250MHz
    • 5250MHz to 5350MHz
    • 5470MHz to 5725MHz
    • 5725MHz to 5825MH
  • WARRANTY
    • 1 year
  • COUNTRY OF ORIGIN
    • Thailand
  • WEIGHT
    • 1.1 lbs. (500g)
  • DEVICE DIMENSIONS
    • 6.0” (L) x 1.5” (H) x 6.4” (D)
  • PACKAGING DIMENSIONS
    • 11.4” (L) x 2.5” (H) x 10.4” (D)
  • INCLUDED ACCESSORIES
    • 1x HDMI cable, 1.8m
    • 1x CAT 5E, 3.6m, shielded
    • 1x USB Type-A Type-B, 2.0m
    • 1x Power module (regional choices available when ordering)
    • Wall mount kit
  • PART NUMBER
    • PN: 7200-84685-xxx (regional choices available when ordering)
    • PANO APP
      • Windows 7, 8 & 10
      • MAC OS X
      • 1080p, 30fps
    DOWNLOAD DATA SHEET
